New Product: 100-130W Medical GaN Desktop - EM1107 Series
Introduction
In response to the continued shift toward high efficiency, low power consumption, and compact design in medical equipment, EDAC POWER introduces the EM1107 Series, a GaN-based medical-grade AC/DC desktop power supply. Offering output power from 100W to 130W, the EM1107 Series is designed to meet the diverse performance requirements of clinical applications.
Built with advanced GaN components, the EM1107 Series enhances thermal conductivity and reduces component size, achieving up to 93% conversion efficiency. It supports a wide output voltage range from 12V to 56V and is suitable for various medical devices, including ECG(Electrocardiogram) System, blood analyzers, CPAP (Continuous Positive Airway Pressure) devices, medical-grade touchscreen monitors, medical air compressor systems, alarm units, physical therapy equipment, rehabilitation devices, medical PTZ cameras, and other medical equipment.
The EM1107 Series complies with IEC/EN 60601-1 medical safety standards as well as IEC/EN 62368-1 for ITE equipment, and is designed with 2 x MOPP (Means of Patient Protection), providing double insulation to ensure electrical safety for both patients and users in clinical environments.
Additionally, the product is equipped with multiple protection mechanisms, including over voltage (OVP), over current (OCP), short circuit (SCP), and over temperature protection (OTP). Auto-recovery or latch-off options are available based on specific application requirements, ensuring stable and secure operation of medical equipment.
Customized solutions are available for GaN power series, please contact our sales team for your demands: sales@edac.com.tw
Product Highlights
- 2 x MOPP Compliance, IEC/EN60601-1 Compliance
- Gallium Nitride Based Design
- LED Indicator
- Active PFC Function
- Protections : Short circuit / Over voltage / Over current
Over temperature - Efficiency up to 93%
- No Load Power Consumption ≤ 0.21W(VI) , ≤ 0.15W(CoC Tier II)
- MTBF > 100,000 hours
