New Product: 3200W CRPS Module Power Supply - ES23200 Series
Introduction
The ES23200 series CRPS Module is designed for high- power applications such as servers, high- performance computing ( HPC ), data centers , network communication equipment, and enterprise-class storage systems . It can provide up to 3200W of output power. With high power density design, it also takes into account high efficiency, reliability and intelligent power management capabilities , helping the system maintain stable power supply and optimal performance under long- term and high -load operating conditions.
Breakthrough: Wide input range and high efficiency
Wide-range input the ES23200 series Supporting a wide input range of 100–240VAC or 180–320VDC , it can meet the power requirements of various global power environments , enhancing system deployment flexibility. With an 80 PLUS® Titanium efficiency rating, the product is particularly suitable for high- density servers and data centers operating continuously for extended periods , significantly reducing operating electricity costs and data center cooling costs. Its long-term energy-saving benefits are extremely significant, and it complies with ESG standards .
In addition, the ES23200 series features built-in I²C communication and supports the PMBus protocol, enabling real-time acquisition of power status and parameters for convenient system management and remote monitoring . It also integrates a 256-Byte EEPROM , facilitating system parameter setting, data storage, and maintenance management, significantly enhancing intelligent power management capabilities .
Leading: Intelligent Redundancy Architecture and Complete Protection Mechanism
The product supports parallel operation and adopts active current sharing. It can be paired with N +M intelligent redundancy ( N+M ≤ 4 ) to build a high- reliability backup system. Even if a single power module malfunctions , it can still maintain stable and uninterrupted system operation . High- reliability protection design and intelligent redundancy architecture reliability have always been the core of enterprise-level power supply design .
The ES23200 series has a built-in comprehensive security protection mechanism that can effectively protect system and equipment security under abnormal conditions, including:
- Short Circuit Protection
- Overvoltage Protection
- Under Voltage Protection
- Overcurrent Protection
- Over-temperature protection
The ES23200 series features a compact size of 185mm (L) x 73.5mm (W) x 40mm (H), offering high power and saving rack space . This allows for more computing units to be placed in a limited space , which is beneficial for server and high- density device designs . It meets IT product safety standards (EN/IEC/UL 62368-1) , and features a variable-speed fan cooling design. It also supports operating altitudes up to 5,000 meters , providing excellent environmental adaptability . Furthermore, dual LED status indicators and fault alarms allow for real-time monitoring of power supply status, providing higher maintenance efficiency and system reliability .
For further specification requirements or customized project needs, please contact our sales team: sales@edac.com.tw
Product Highlights
- 3200W high power output
- Wide input range: 100–240VAC / 180–320VDC
- Safety protection against output short circuit, overvoltage, undervoltage, overcurrent, and overtemperature.
- 80 PLUS® Titanium Super Efficiency
- Built-in I²C communication, supporting PMBus protocol
- Built-in 256-bit EEPROM
- Parallel operation with active current sharing
- N+M intelligent redundancy ( N+M ≤ 4 )
- Variable speed fan cooling
- Support the highest working altitude of 5,000 meters
- Dual LED status indicator and fault alarm
